Pre Connectorized Fiber Optic Drop Cable SC APC To SC APC 150m

  • 1
  • 2
  • 3

Brand Name : Unifiber or OEM

Model Number : FTTH Outdoor Pre-connectorized Drop Cable

Certification : ROHS

Place of Origin : China

MOQ : 10

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 10000pcs/day

Delivery Time : 3~5days

Packaging Details : Carton Box

Product : FTTH Outdoor Pre-connectorized Drop Cable

Connector : Huawei mini SC/APC

Cable Diameter : 5.0mm

Cable Jacket : LSZH

Fiber Type : G657A2

Length : 150m

Contact Now

Mini SC assemblies provide a robust and sealed connection solution for fiber to the home (FTTH) connectivity.Huawei Compatible Mini SC pre-terminated OSP drop cables provide easy FTTx (Fiber-To-The-X) installation and termination using existing hardware and installation methods for drops to homes and businesses. Its flat profile is compatible with existing wedge (P) clamps.The Ruggedized Connector, an outside plant Mini SC/APC, is compatible with industry standard OSP terminals.

Features And Benefits:
1. Provides superior weather resistance for FTTA and other outdoor applications.
2. Allows flexibility to use factory terminated assemblies or pre-terminated or field installed assemblies
3. Suitable for FTTA and outdoor temperature extremes Ensures functionality in harsh weather environments
4. Can be installs without special tooling
5. Threaded style coupling
6. Provides bend protection for installation and long term use
7. Faster network roll out and customer installations
8. 100% tested assemblies built in a controlled environment
9. Lower cost deployment by utilizing plug and play solutions
10. Custom built solutions with quick turnaround times

Specification

Items
SM-UPC
SM-APC
MM-UPC
Typical
MAX
Typical
MAX
Typical
MAX
Insertion loss
≤0.1
≤0.3dB
≤0.15
≤0.3dB
≤0.05
≤0.3dB
Return loss
≥50dB
≥60dB
≥30dB
Durability
1000 mating cycles
Working temperature
-40 to + 85℃
Pre Connectorized Fiber Optic Drop Cable SC APC To SC APC 150m
Pre Connectorized Fiber Optic Drop Cable SC APC To SC APC 150m
Pre Connectorized Fiber Optic Drop Cable SC APC To SC APC 150m
